技術參數：

1型號 3Z-2C-200

2材料形式卷料

3最大檢測進料寬度 200mm

4最大運行速度20米/分鐘

5額定功率 4Kw

6.額定電壓 220V±10%

7.外形尺寸1900* 3000*1000mm(高*長*寬）)

8.整機重量約0.7T

Technical parameters

1. model 3Z-2C-200

2. Material Roll

3. Maximum test material width 200mm

4. Maximum operating speed 20m/min

5. Rated power 4kw

6. Rated voltage 220v±10%

7. Dimensions1900* 3000*1000mm(H*L*W)

8. Weight 0.7T

主要性能特點：

1.操作系統：21寸大屏液晶顯示器，中英文操作系統，界面友好，操作簡單、方便、靈活；

2.自主研發的控制系統，功能可定向開發；

3. 具有工藝參數存儲功能，調用靈活；

4. 最高速度20米/分鐘；

5. 最大檢測進料寬度200mm;

6. 每套軸均由單獨的伺服系統驅動，通用于收料、放料、改變方向、擬人化啟動；

7. 計片、計米報警停機功能，能夠按設定數量自動控制設備停止；

8. 各收、放料軸可分別選擇自動恒張力控制或恒轉矩控制模式；

9. 斷料報警停機功能，料軸材料用完或斷料后控制設備自動停機，防止料頭卷入設備；

10. 各收放料軸均配有一鍵式啟動/停止按鈕，更便于操作人員換料作業；

11. 具備尺寸測量與表面缺陷檢測雙功能，也可單獨開啟尺寸測量功能或者表面缺陷檢測功能；

12. 尺寸測量有效視野為40mm*40mm，可同時測量10個以上尺寸；

13. 表面缺陷可檢測堵孔、異物、變形、多膠、缺膠、漏排廢等缺陷；

14. 缺陷檢測有效視野為160mm*150mm（大于該視野可選配不同型號鏡頭）；

15. 不良品處理模式：準確位置停機報警與在線打標兩種模式。高速準確停機報警，停機后一鍵高速復原啟動，在線打標(選配)；

1. Operating system: 21-inch touch HMI panel on swing arm with separate rail mounted consoles for easy operator access.

2. Self-developed control system, function customization can be realized.

3. Synchronous control system for die cutting with short synchronous period and quick response.

4. With the function of Storing all process parameters for each product, and flexible call.

5. Maximum cutting speed of 20 meters/min (200 ft/min).

6. Maximum material width of 200 mm (10”).

7. Each set of die cutting station is controlled by certain servo drive for start, stop, forward, reverse, synchro, scale, trimming functions.

8. Each set of material shafts is driven by a separate servo system, which is used for receiving, discharging, changing direction, and anthropomorphic start-up.

9. With rectification function: automaticallyadjust the Y direction of the main feed axis.

10. The die-cutting tool speed can be easily adjusted independently.

11. The chip and meter alarm stop function can automatically control the device to stop according to the set quantity.

12. Each receiving and discharging axis can select automatic constant tension control or constant torque control mode respectively.

13. Island placement modules available, registered dispensing of smaller die cut components onto other components, or pre-printed web features, minimizes material waste.

14. Each of the retractable material shafts is equipped with a one-button start/stop button, which is more convenient for the operator to refuel the operation.

15. Effective visual field of dimension measurement is 40mm*40mm, more than 10 dimensions can be measured at the same time

16. The surface defect such as hole blocking, foreign body deformation, glue missing, glue leakage and waste discharge

17. The effective visual field for defect detection is 160mm*150mm (larger than this visual field, different types of lenses are optional).

18. Processing mode of defective products: accurate position shutdown alarm and online markinghigh-speed accurate shutdown alarm, one-button high-speed recovery start after shutdown, online marking (optional)
